6082 T6 aluminum extrusion profile is a heat-treated and strengthened aluminum alloy profile with high strength, good corrosion resistance and excellent processing performance. It is widely used in structural components in shipbuilding and other marine environments, especially where high strength and durability are required. Compared with other aluminum alloys, 6082 has higher mechanical properties in the T6 state, which is particularly suitable for frames, supports and other structural parts in shipbuilding.
6082 T6 aluminum extrusion profile specifications
| Alloy | 6082 6063 6061, etc |
| Temper | T6, T651, etc |
| Thickness | 3-50mm |
| Length | 100-16000mm, customizable |
| Sectional shape | T-type, rectangular, round, square, etc. |
| Packaging | Wooden pallets or wooden boxes are suitable for long-term seaworthy transportation. |
| MOQ | 1-3 tons |
6082 Aluminum alloy composition
| Alloy | Si | Fe | Cu | Mn | Mg | Cr | Zn | Ti | Al |
| 6082 | 0.7-1.3 | 0.5 | 0.10 | 0.4-1.0 | 0.6-1.2 | 0.25 | 0.20 | 0.10 | remainder |
6082 T6 Aluminum alloy mechanical properties
| Aluminum alloy | Tensile strength | Yield strength | Elongation/% | Hardness/ HBWα |
| 6082 T6 | 290 | 240 | 10 | 95 |
Reasons for being suitable for shipbuilding
1. Lightweight: 6082 T6 aluminum alloy is lighter than traditional steel, reducing the overall weight of the ship, improving speed and fuel efficiency.
2. High strength and structural stability: Suitable for high-strength parts such as ship frames and support beams, with good load-bearing capacity.
3. Weather resistance and long life: Corrosion resistance, can maintain structural integrity in the marine environment and extend service life.
4. Green and environmentally friendly: Aluminum is a recyclable material, in line with environmental protection trends, and suitable for green building needs.
5. Excellent weldability: The alloy is easy to weld and can be firmly connected with other aluminum alloys or metals
6. Excellent processing performance: 6082 aluminum alloy is easy to extrude and can be made into profiles of various shapes and sizes to meet different design requirements.
Application areas of 6082 T6 aluminum extrusion profiles in shipbuilding
1. Ship structure: high strength and corrosion resistance, suitable for ship frames, decks and bulkheads, able to withstand weight, wind and seawater corrosion.
2. Building curtain walls and doors and windows: used for curtain walls and door and window frames, lightweight and high strength, providing good sound insulation and heat insulation effects, extending the service life of the building.
3. Other building applications: can be used for sunshades, railings, handrails, etc., which are both beautiful, durable and safe.
